ISO 5675

Hydraulic quick coupling > ISO 5675

Product Name:BT-S5C Bulkhead Push and Pull Type Quick Coupling
Model:BT-S5C

Online Service
E-mail Us
NO PDF
Skype

1. Comply to ISO5675 standard
2. Double acting sleeve for one hand operation when coupler is clamp mounted
3. Coupler and nipple are precision machined from steel solid bar and wear points hardened for resistance to damage by hydraulic surges and crash
4. Knurling sleeve provide a gripping surface for ease draw-back
5. High quality Zinc plated protect products from terrible environment effectively
6. Interchangeable with PARKER 4250
Application:These quick couplings are “Pull-Push” and have their main field of application in agriculture,such as mobile plant, trailers and Miner truck.

Body  Size(inch) M14*1.5 M16*1.5 M18*1.5 M22*1.5 M24*1.5 M30*2
 Rated PressurePSI) 3000
 Rated Flow(GPM) 12
 Temperature Range                           -20+80
 Standard Seal NBR On request EPDM,VITON and FKM seals
 Thread METRIC
